eterio 215 RE1

    Etherio 215 RE1 server is a efficient two-processor configuration in a 1U  RACK chassis , using Intel Xeon Scalable processors. It offers a wide range of processors for a variety of applications, and 12 slots for DDR4 memory modules fit into the optimal performance of a six channel memory controller. Extension slots are available for standard PCI Express cards and in addition you can use a disk controller in the form of a mezzanine card mounted in a dedicated slot directly on the motherboard.

    Processors

    Intel Xeon Scalable processors is a new family of products with diverse performance and functionality. Depending on the features they have been divided into classes: Bronze, Silver, Gold and Platinum. They differ in the number of cores, the base frequency, the presence or absence of Turbo mechanisms, the number of built-in units for floating point calculations (AVX-512 FMA units), the number of UPI connectors and even the max speed and capacity of supported RAM. They have built-in network interfaces (Ethernet) and support more PCIe lines than the previous generation. Among the multiple models, you can choose the one which perfectly suits your needs.

    Memory

    The server supports DDR4 Registered DIMM ECC (RDIMM), and Load Reduced DIMM (LRDIMM) with operating frequencies depending on the type of processor used and the available bandwidth of the UPI link. The 2400 MHz, 2666 MHz and 2933 MHz modules are available. In total up to 1,5TB RAM in 12 RDIMM modules and also 1,5TB  RAM in LRDIMM modules is supported. The modules can work in max. 6-channel configurations – this is the optimal setup for best performance.

    Storage

    Depending on the choice of chassis, standard 3.5 “drives or 2.5” drives are supported. All types of disks are supported: SATA, SAS or SSD.

    Chassis

    1U RACK chassis supports up to four standard (3.5 “) SAS / SATA hot-swap discs or 8 2.5” (SFF) SAS / SSD hot-swap disks. In addition, the slim optical drive bay is available. The chassis allows the use of PCI Express expansion cards in two slots accepting full-height cards and one slot for “low-profile” cards. Chassis versions with single or dual power supply are available.

    Specification

    Chassis RACK 1U, 4 x hot-swap
    Bays: 4 x 3,5″ – hot-swap SATA
    1 x Slim 5,25″ (eg. DVD)
    1 x Slim 3,5″ (eg. optional front ports: 2 x USB + COM)
    4-6 internal redundant fans
    Power Supply:  single 600W (80PLUS Platinum) or 750W redundant (80PLUS Platinum)
    Dimensions (height x width x depth): 43 x 437 x 597 mm

    Rack 1U, 8 x hot-swap
    Bays: 8 x 2,5″ – hot-swap SAS/SATA
    1 x Slim 5,25″ (eg. DVD)
    4-6 internal redundant fans
    Power Supply:  single 600W (80PLUS Platinum) or 750W redundant (80PLUS Platinum)
    Dimensions (height x width x depth): 43 x 437 x 597 mmm

    Processor

    Intel® Xeon® Scalable (Skylake EP)

    Second Generation Intel® Xeon® Scalable (Cascade Lake)

    Memory slots

    12

    Max. CPU

    2

    Chipset

    Intel C621 (the mianboard with 1GbE LAN),

    Intel C622 (the mianboard with 10GbE LAN)

    Memory

    DDR4 Registered ECC, DDR4 3DS RDIMM, DDR4 3DS LRDIMM

    Max supported memory

    1,5 TB

    Available modules

    8 GB

    16 GB

    32 GB

    64 GB

    128 GB LRDIMM

    Memory protection

    Memory Mirroring

    Memory Sparing

    ECC, SDDC

    Integrated controllers IIntel C621/C622,  SATA3 (6Gbps), 14 ports (including two supporting SATA DOMs)
    Expansion slots 2 x PCIe 3.0 x16 FH
    1 x PCIe 3.0 x8 LP
    I/O ports 1 x VGA
    2 x LAN (RJ45)
    1 x LAN (RJ45) – dedicated for management
    6 USB 3.0:
    – 4 x rear USB 3.0
    – 2 x optional (on-board connector)
    Management

    Intel Node Manager 3.0
    IPMI 2.0
    SuperDoctor 5
    “Remote KVM” and “Media Redirection” functionality

    Supported OS

    Red Hat Enterprise Linux Server 7.x

    SUSE Linux Enterprise Server 12 (64-bit)

    Microsoft Windows Server 2012

    Microsoft Windows Server 2012 R2

    Microsoft Windows Server 2016

    Microsoft Windows Server 2019

    Windows 10

    Notice There are integrated: i-SATA controller (8 ports – two miniSAS HD connectors) and s-SATA (4 ports – one miniSAS HD connector, 2 standard SATA connectors with power connection for SATA DOM). When creating RAID sets, you can not use disks connected to different controllers in one storage volume.
    Energy management

    YES

    Additional info The board is equipped with an M.2 socket for NVMe disks (PCI Express) and a slot for micro SD card
    Integrated VGA

    BMC integrated Aspeed AST2500

    Integrated LAN

    2 x 1 Gigabit Ethernet, RJ-45 (or 2 x 10 Gigabit Ethernet, 10G BASE-T, RJ-45 – upon motherboard model upgrade)

    Chassis

    RACK 1U

    Certified OS Microsoft Windows Server 2016

    Microsoft Windows Server 2019

    TPM

    TPM 2.0 internal header (optional)
